  • Developing a realtime full stack app with .NET, Angular, and MongoDB

    By: Michał Niegrzybowski 14 min read

    In today's tutorial we are going to create a simple retrospective app. It will save information about the discussed topics and show them to users in real time so they can easily see the previous, current, and future topics during the current meeting. The code is written in .NET 5. It’s divided into several services, every one of them responsible for a single context.

    We assume that every service should contain health checks, OpenAPI documentation, and is run via
    docker-compose.

    As a data store we are going to use MongoDB.

    Architecture of the retrospective app

    The application will be divided into 3 services:
    Facade is a front-end of an application that directs requests from clients to other services mentioned below.
    Topic is responsible for saving retrospective topics to a database (MongoDB).
    Notification collects all notifications from other services and pushes them to subscribed services/clients. For the purposes of this demonstration, we can  assume that it works like a push notification.

    Communication between each of them is done via publish/subscribe.

    Here is the architecture diagram:

    The architecture of the app specifies 3 main services – Topic, Notification, and Facade – underpinned by Ably's infrastructures and services.
    Architecture diagram for the realtime fullstack app.

    To simplify the above, we are going to use an out-of-the-box pub/sub service. Ably fits the bill for reasons that follow.

    What is Ably?

    Ably delivers several services including pub/sub, history of message persistence, push notifications for mobile apps, among others. It also has a .NET library ready to use.

    As a short introduction, I want to describe some base terms used in Ably:

    Channel is a source of communication for services/clients which are connected to it.
    Message Type is used to distinguish different types of data sent via a single channel. Services can subscribe to a concrete type(s) or to all of them.

    Dive to the Code

    We can check right now what the code looks like.

    Facade

    The first service, Facade, shows information to a client. Service is written in .NET 5 (C#). It’s a WebAPI with a frontend part written in Angular 8.

    OpenAPI and Healthchecks

    This service depends only on Ably, because the startup file contains a recipe to check Ably state and generate OpenAPI documentation via Swashbuckle.

    public void ConfigureServices(IServiceCollection services)
    {
        var config = Configuration
            .GetSection("Ably")
            .Get<AblyConfig>();
        var ably = newAblyRealtime(config.ApiKey);

        services.AddSwaggerGen(c =>
        {
            c.SwaggerDoc("v1",newOpenApiInfo{Title="WebAppAPI",Version="v1"});
        });
        services.AddHealthChecks()
            .AddCheck(
                "AblyChannel",
                newAblyChannelHealthCheck(
                    ably,
                    "Topic"
                )
            )
            .AddCheck(
                "AblyTimer",
                newAblyTimerHealthCheck(
                    ably,
                    "Topic",
                    FSharpOption<TimeSpan>.Some(TimeSpan.FromSeconds(1)),
                    FSharpOption<TimeSpan>.Some(TimeSpan.FromSeconds(1))
                )
            );
        services
            .AddHealthChecksUI(s =>
                s
                    .SetEvaluationTimeInSeconds(60)
                    .AddHealthCheckEndpoint("Self",$"http://{Dns.GetHostName()}/health"))
                    .AddInMemoryStorage();
            );
        …
        services.AddAutofac();
        …
    }

    public void Configure(IApplicationBuilder app,IWebHostEnvironment env)
    {
        …
        app.UseSwagger();
        app.UseSwaggerUI(c =>
        {
            c.SwaggerEndpoint("/swagger/v1/swagger.json","DashboardAPIV1");
        });

        app.UseEndpoints(endpoints =>
        {
            endpoints.MapControllerRoute(
                name:"default",
                pattern:"{controller}/{action=Index}/{id?}");
            endpoints.MapHealthChecksUI( setup =>
                {
                    setup.UIPath="/ui-health";
                    setup.ApiPath="/api-ui-health";
                }
            );
            endpoints.MapHealthChecks(
                "/health",
                newHealthCheckOptions {
                    Predicate=( _ => true),
                    ResponseWriter=UIResponseWriter.WriteHealthCheckUIResponse
                }
            );
        });

        ...
    }

    Swagger generates the interface definition for Facade, including 3 methods: POST, PUT, and GET.
    Swagger-generated method spec for Facade
    On the dashboard, you can check the health of the Ably Channel and the Ably Timer (including Description, Duration, and Details fields).
    Dashboard view of health checks.

    Actions

    Service contains a single controller with 2 actions: POST and PUT (the GET action is here only for testing purposes). POST creates a topic, PUT updates it.

    [HttpPost]
    public async Task<StatusCodeResult> Save([FromBody]CreateDto create)
    {
        var data = new Topic
            (
                name: Name.NewName("name"),
                id: Identifier.NewId(""),
                creator: Creator.NewCreator(create.Creator),
                description: Description.NewDescription(create.Description),
                done: Done.NewDone(false)
            );

        var channel = _ably.Channels.Get(_ablyConfig.Topic.Name);
        var result = await channel.PublishAsync(_ablyConfig.Topic.MessageType,data);
        if (!result.IsFailure)
            returnOk();
        _logger.LogError(result.Error.Message);
        return new StatusCodeResult(500);
    }


    Looking at the code, we can see that user requests come to a controller action with the DTO object. This object is then transformed into a message that is known by the Topic service. After that, the message is sent via Ably via the topic channel.

    Ably registration

    Here we use an Ably service which is injected into a controller, but it is worth showing what its registration looks like. We use Autofac as DI and the whole code is below:

    public class WebAppModule : Module
    {
        private readonly AblyConfig _config;

        public WebAppModule(AblyConfig config) => _config = config;

        protected override void Load(ContainerBuilder builder)
        {
            base.Load(builder);

            builder.Register(_ => _config).AsSelf().SingleInstance();
            builder.Register(_ => new AblyRealtime(_config.ApiKey)).AsSelf().SingleInstance();
        }
    }
    public void ConfigureContainer(ContainerBuilder builder) =>
        builder.RegisterModule(new WebAppModule(Configuration
            .GetSection("Ably")
            .Get<AblyConfig>()));
    public class Program
    {
        public static Task Main(string[] args) =>
            CreateWebHostBuilder(args).Build().RunAsync();

        private static IHostBuilder CreateWebHostBuilder(string[] args) =>
            Host.CreateDefaultBuilder(args)
                .UseServiceProviderFactory(new AutofacServiceProviderFactory())
                .ConfigureWebHostDefaults(wb =>
                {
                    wb.UseStartup<Startup>();
                    wb.ConfigureLogging((ctx, lg) =>
                    {
                        lg.ClearProviders();
                        lg.AddDebug();
                        lg.AddConsole();
                    });
                });
    }


    The app's user interface (in Angular 8)

    The frontend part as mentioned earlier is written in Angular 8. Looking at the code, we have two main Angular components:

    Home-component.ts shows the main page with a list of actual topics and a form to add a new topic.
    Activity-component.ts shows a page with all user activities.

    Home component

    The first component which shows the main page is divided into two parts. The first part shows a form to add a new topic which is extracted as a separate component (create-component.ts) and it looks as follows:

    export class CreateComponent {
      public model: Create = { Description: "", Creator: "" };
      constructor(
        private readonly http: HttpClient,
        @Inject('BASE_URL') private readonly baseUrl: string) {
      }

      public onSubmit = () =>
        this.http.post(
            `${this.baseUrl}Facade`,
            JSON.stringify(this.model),
          { headers: { 'content-type': 'application/json'}})
          .toPromise()
          .then(_ => this.reset());

      public reset = () =>
        this.model = { Description: "", Creator: "" }
    }

    The component view has a form for the Retrospective List app where you can add a new topic as well as mark a topic as "done".
    The component view of the Retrospective List.

    In the component view, we see a form to create a new topic to discuss. What happens inside the form logic? We map data from a form and send it to the server upon clicking the Submit button.

    The second part of the home component contains a table with all topics that were created and discussed. When we create a topic, it doesn't show up immediately on a list because it comes from a server via the Ably channel.

    To receive such a message, we attach to an Ably channel (Notification channel).

    export class HomeComponent {
      public topics: Topic [];

      constructor(
        private readonly http: HttpClient,
        private readonly changeDetector: ChangeDetectorRef,
        @Inject('BASE_URL') private readonly baseUrl: string) {
        this.http.get(`${this.baseUrl}Facade`)
          .toPromise()
          .then((e: AblyConfig) => {
            let client = new Ably.Realtime({ key: e.apiKey });
            let channel = client.channels.get(e.push.name);
            channel.subscribe(e.push.messageType, msg => {
                let additionalData = JSON.parse(msg.data).AdditionalData.Item;
                let newRecord = JSON.parse(additionalData);
                this.topics = [newRecord, ...this.topics];

                this.changeDetector.detectChanges();
              })
            });
        this.topics = [];
      }

      public markAsDone (model) {
        this.http.post(
          `${this.baseUrl}Facade`,
          JSON.stringify(model),
          { headers: { 'content-type': 'application/json'}})
          .toPromise()
          .then(_ => {
            this.topics = this.topics.filter(x => x !== model);
            this.changeDetector.detectChanges();
          });
      }
    }


    Note that the code needed to create an Ably object, attach to a channel, and listen for an incoming message is very similar to what we show on the server-side.

    In short, we fetch the channel, subscribe to it, and when a message of interest comes in we update the model of the home component. Also note the markAsDone method which handles marking a topic as "already discussed" which in turn fires an update on a certain topic.

    Activity Feed

    The second main component (activity-component.ts) is responsible for showing a history of all events that occurred in the application. It looks similar to the home page, but the messages arrive in a slightly different way.

    export class ActivityComponent {
      public activities: Topic [];
      constructor(
        private readonly http: HttpClient,
        private readonly changeDetector: ChangeDetectorRef,
        @Inject('BASE_URL') private readonly baseUrl: string) {
        this.http.get(`${this.baseUrl}Facade`)
          .toPromise()
          .then((e: AblyConfig) => {
            let client = new Ably.Realtime({ key: e.apiKey });
            let channel = client.channels.get(e.push.name);
            channel.attach(err => {
              channel.history({untilAttach: true}, (error, results) => {
                let isMsg = (maybeMsg: PaginatedResult<Message> | undefined):
                  maybeMsg is PaginatedResult<Message> =>
                    (maybeMsg as PaginatedResult<Message>) !== undefined;

                if (isMsg(results))
                  this.activities =
                      results
                      .items
                      .map(msg => {
                        if (msg.name === e.push.messageType) {
                          let additionalData = JSON.parse(msg.data).AdditionalData.Item;
                          return JSON.parse(additionalData);
                        }
                        else {
                          return { Creator: "Server request", Description: "Server request", Id: msg.id, Done: false };
                        }
                      });
                else
                  this.activities = [];
                this.changeDetector.detectChanges();
              })})
          });
      }
    }


    We don't fetch the channel, but directly attach to it and listen to all the messages that have come via this particular channel in the last 24 hours. The persist information is set on the Ably platform per channel. We are not able to set it in a programmatic way, but via the channel page.

    Message retention

    To set message retention,  we need to go to the Ably dashboard and navigate to the channel page:

    On the Channel rules view of the Ably dashboard you can view all the selected presets such as "Persist last message", "Persist all messages", "Push notifications enabled", and whether TLS or ID are required.
    Channel rules view on the Ably dashboard.
    On the Edit Channel Rule page, you can toggle on and off all pertinent settings for your channel, such as "Persist last message", "Persist all messages", "Push notifications enabled", and whether TLS and ID are required.
    Edit channel rule page on Ably dashboard

    Enable "Persist all messages" and that's all.

    On the Last Activity dashboard of the Retrospective app you can view the last activities including ID, Owner, and Description.
    Last activity dashboard for the Retrospective app

    Right now we know how it works on a client and Facade side. We can also forward to the Topic and
    Notification services.

    Topic

    Topic is a WebAPI written in .NET 5 (F#). It uses MongoDB as a database. It has 3 main responsibilities:

    1. Receiving and handling messages about new topics.
    2. Saving topics to Database.
    3. Notifying about handled topics.

    Handle Ably messages

    Topic subscribes to all messages of interest, specifically those that are meant to create or update topics. The main responsibility of service is to handle said messages which are sent via Ably Channel in accordance with the requirements.

    member private this.ConfigureHandlers (di: DI) (logger: ILogger<Startup>) =
        let channel = di.ably.Channels.Get di.ablyConfig.Topic.Name
        channel.Subscribe(
            di.ablyConfig.Topic.MessageType,
            fun msg ->
                async {
                    match! Topic.Application.Topics.Save.trySave di msg.Data CancellationToken.None with
                    | Choice1Of2 result -> logger.LogDebug $"Process message: {result}"
                    | Choice2Of2 err -> logger.LogError $"Error occurred while processing message: {err}"
                    ()
                } |> Async.RunSynchronously)


    When the new message comes, we receive it and map it to a business model.

    type InvalidTopicFormat = exn

    [<RequireQualifiedAccess>]
    module Save =
        let save
            (di: DI)
            topic
            token =
            async {
                let! result = Repository.create token di.config topic

                match result with
                | Choice1Of2 (DTOResult.Create data) ->
                    let serializedData = JsonSerializer.Serialize(data, Serialization.serializerOpt)
                    let (Topic.Contract.Id id) = data.Id
                    let msg = {
                        Id = Identifier (Guid.NewGuid())
                        RelatedId = Id id
                        AdditionalData = AdditionalData serializedData
                    }
                    let channel = di.ably.Channels.Get di.ablyConfig.Notification.Name
                    let! pubResult = channel.PublishAsync (di.ablyConfig.Notification.MessageType, msg) |> Async.AwaitTask
                    if pubResult.IsFailure then
                        return Choice2Of2 (pubResult.Error.AsException ())
                    else return result
                | Choice1Of2 res ->
                    di.logger.Log(LogLevel.Warning, $"Expected to get a create result, but got something else: {res}")
                    return result
                | Choice2Of2 ex ->
                    di.logger.Log(LogLevel.Error, $"Error occurred while processing data in repository: {ex.Message}")
                    return result
            }

        let trySave
            (di: DI)
            (topic: obj)
            token =
            async {
                try
                    let deserializedTopic = (topic :?> JObject).ToObject<Topic>()
                    return! save di deserializedTopic token
                with msg ->
                    return
                        msg.Message
                        |> InvalidTopicFormat
                        |> Choice2Of2
            }



    Saving data to MongoDB

    Then we save it to MongoDB which we run as a docker image (the same way as .NET services).

    version: '3'
    volumes:
      retrospectiveLocalDb:
      retrospectiveLocalDbConfig:
    services:
      database:
        image: db
        build:
          context: ./storage/mongo
          dockerfile: ./Dockerfile
        environment:
          - MONGO_INITDB_ROOT_USERNAME=sample
          - MONGO_INITDB_ROOT_PASSWORD=Sample123!
        volumes:
          - retrospectiveLocalDb:/data/db
          - retrospectiveLocalDbConfig:/data/configdb
        ports:
          - '27017-27019:27017-27019'
    FROM mongo:4.2.3
    COPY init-mongo.js /docker-entrypoint-initdb.d/
    db = db.getSiblingDB('admin')
    db.createUser(
        {
            user: "admin",
            pwd: "123",
            roles: [
                { role: "readWrite", db: "admin" }
            ]
        });

    db = db.getSiblingDB('retrospective')
    db.createUser(
        {
            user: "admin",
            pwd: "123",
            roles: [
                { role: "readWrite", db: "retrospective" }
            ]
        });
    let private queryDb token config ``type`` (model: Option<Topic>) =
        match ``type`` with
        | TopicOperation.Create ->
            async {
                let fOpt = InsertOneOptions ()

                let! _ =
                    connection config
                    |> Query.insertOne token fOpt model.Value
                return QueryResult.Create model.Value
            }
        | TopicOperation.Update ->
            async {
                let fOpt = FindOneAndReplaceOptions<Topic> ()
                fOpt.ReturnDocument <- ReturnDocument.After
                let filter =
                    Filter.eq (fun (x: Topic) -> x._id) model.Value._id

                let! result =
                    connection config
                    |> Query.updateWhole token fOpt model.Value filter
                return QueryResult.Update result
            }
        | ...

    ...

    let private query token config data ``type`` =
        async {
            let! mapped = ToDomain.map data
            return! mapped |> (queryDb token config ``type``)
        }

    ...

    let create token config data =
        async {
            let! result = query token config (Some data) TopicOperation.Create
            return result |> ToDTO.map
        } |> Async.Catch


    The code doesn't look too complicated. Easy maps from object to object and saves to the database. When the save succeeds we want to inform the client application about this fact. Because our project can contain a lot of other services, we created a service that will aggregate all kinds of push messages in one place.

    Forward message to Notification

    We map all the aggregated messages that were successfully saved to an object acceptable by the
    Notification service, and send it to it over the Ably channel. This is done the same way that
    Facade sends data to Topic service, except we are using different channels and message types.

    ...
    match result with
    | Choice1Of2 (DTOResult.Create data) ->
        let serializedData = JsonSerializer.Serialize(data, Serialization.serializerOpt)
        let (Topic.Contract.Id id) = data.Id
        let msg = {
            Id = Identifier (Guid.NewGuid())
            RelatedId = Id id
            AdditionalData = AdditionalData serializedData
        }
        let channel = di.ably.Channels.Get di.ablyConfig.Notification.Name
        let! pubResult = channel.PublishAsync (di.ablyConfig.Notification.MessageType, msg) |> Async.AwaitTask
        if pubResult.IsFailure then
            return Choice2Of2 (pubResult.Error.AsException ())
        else return result
    | Choice1Of2 res ->
        di.logger.Log(LogLevel.Warning, $"Expected to get a create result, but got something else: {res}")
        return result
    | Choice2Of2 ex ->
        di.logger.Log(LogLevel.Error, $"Error occurred while processing data in repository: {ex.Message}")
        return result
    …


    Open API and HealthChecks

    In contrast to Facade, the Topic service depends on two things. The first one is  Ably. The second one is MongoDB which we describe in health checks.

    member this.ConfigureServices(services: IServiceCollection) =
        let config = Config ()
        this.Configuration.Bind config
        let ably = new AblyRealtime (config.Ably.ApiKey)
        let loggerFactory =
                LoggerFactory.Create(fun builder ->
                builder.AddConsole() |> ignore
                );
        let logger = loggerFactory.CreateLogger<Startup>()

        let di = DI.create config ably logger
        services.AddSingleton<DI> (fun _ -> di) |> ignore

        this.ConfigureHandlers di logger

        services.AddSwaggerGen(fun c ->
                c.SwaggerDoc("v1", OpenApiInfo(Title = "Topic Api", Version = "v1"))
        ) |> ignore

        services.AddHealthChecks()
            .AddCheck(
                "Ably Channel",
                AblyChannelHealthCheck(
                    ably,
                    "Topic"
                )
            )
            .AddCheck(
                "Ably Timer",
                AblyTimerHealthCheck(
                    ably,
                    "Topic",
                    TimeSpan.FromSeconds 1.,
                    TimeSpan.FromSeconds 1.
                )
            )
            .AddMongoDb((MongoConfig.map config.MongoDb).GetConnectionString(), name = "MongoDB")
        |> ignore
        services
            .AddHealthChecksUI(fun s ->
                s
                    .SetEvaluationTimeInSeconds(60)
                    .AddHealthCheckEndpoint("Self", $"http://{Dns.GetHostName()}/health")
                |> ignore)
            .AddInMemoryStorage() |> ignore
        ...

    member this.Configure(app: IApplicationBuilder, env: IWebHostEnvironment) =
        ...
        app.UseSwagger(fun opt -> ()) |> ignore
        app.UseSwaggerUI(fun opt ->
                opt.SwaggerEndpoint("/swagger/v1/swagger.json", "Topic Api V1")
                opt.RoutePrefix <- String.Empty
        ) |> ignore
        ...
        app.UseEndpoints(fun endpoints ->
                endpoints.MapControllers() |> ignore
                endpoints.MapHealthChecksUI(fun setup ->
                    setup.UIPath <- "/ui-health"
                    setup.ApiPath <- "/api-ui-health"
                ) |> ignore
                endpoints.MapHealthChecks(
                    "/health",
                    HealthCheckOptions(
                        Predicate = (fun _ -> true),
                        ResponseWriter = Func<HttpContext, HealthReport, Task>(fun (context) (c: HealthReport) -> UIResponseWriter.WriteHealthCheckUIResponse(context, c))
                    )
                ) |> ignore
            ) |> ignore

    Swagger's definition of the Topic API includes methods such as POST, PUT, and GET.
    Swagger's Topic API method definition

    We also define some HTTP endpoints just for testing purposes. You can see them in the OpenAPI documentation as follows.

    On the dashboard, you can check the health of the Ably Channel, the Ably Timer, and MongoDB (including Description, Duration, and Details fields).
    Dashboard view of health checks.

    Notification Service

    Now we can switch to the Notification service. This is again a WebAPI written in .NET 5 (F#).

    Handle Ably messages

    Similar to the Topic service, the Notification Service attaches to the Ably channel for new messages on the concrete channel and then handles them as they come in.

    member private this.ConfigureHandlers (ably: AblyRealtime) (config: AblyConfig) (logger: ILogger) =
        let channel = ably.Channels.Get config.Channels.Notification.Name
        channel.Subscribe(
            config.Channels.Notification.MessageType,
            fun msg -> WebApi.Notifications.Save.handle ably config msg.Data logger |> Async.RunSynchronously)


    Handling messages in the Notification service basically means mapping a message and then sending it over the Ably channel to all interested clients/services. In our scenario, it is a TypeScript part of Facade.

    Forward notification (push) message to all clients

    let private serializerOpt =
        let options = JsonSerializerOptions()
        JsonFSharpConverter(
            unionEncoding = (
                // Base encoding:
                JsonUnionEncoding.Untagged
                // Additional options:
                ||| JsonUnionEncoding.UnwrapOption
                ||| JsonUnionEncoding.UnwrapRecordCases
            )
        )
        |> options.Converters.Add

        options

    let internal handle (ably: AblyRealtime) (ablyConfig: AblyConfig) (msg: obj) (logger: ILogger) =
        try
            let deserialized = (msg :?> JObject).ToObject<Notification.Contract.Message>()
            async {
                let channel = ably.Channels.Get ablyConfig.Channels.Push.Name
                let msg = JsonSerializer.Serialize(deserialized, serializerOpt)
                let! _ = channel.PublishAsync (ablyConfig.Channels.Push.MessageType, msg) |> Async.AwaitTask
                ()
            }
        with er ->
            logger.LogError $"Error occurred while processing notification message: {er.Message}"
            async {
                let channel = ably.Channels.Get ablyConfig.Channels.Push.Name
                let! _ = channel.PublishAsync (ablyConfig.Channels.Push.MessageType, er.Message) |> Async.AwaitTask
                ()
            }


    By omitting backend code, Facade listens to all notifications. We define a more robust type of message serialization (done by Fsharp.System.Text.Json) because we want to serialize all F#-specific types like Unions and Records to make them easily approachable from via TypeScript.

    OpenAPI and Healthchecks

    In the end we configure a small part of the startup.fs file where we define health checks and OpenAPI information. Similar to Facade, the Notification service from an external point of view depends only on Ably services.

    member this.ConfigureServices(services: IServiceCollection) =
        let config = Config ()
        this.Configuration.Bind config
        let ably = new AblyRealtime (config.Ably.ApiKey)
        services.AddSingleton<AblyRealtime>(fun _ -> ably) |> ignore
        services.AddSingleton<Config> (fun _ -> config) |> ignore

        let loggerFactory =
                LoggerFactory.Create(fun builder ->
                builder.AddConsole() |> ignore
                );
        let logger = loggerFactory.CreateLogger();
        this.ConfigureHandlers ably config.Ably logger

        services.AddSwaggerGen(fun c ->
                c.SwaggerDoc("v1", OpenApiInfo(Title = "Notification Api", Version = "v1"))
        ) |> ignore

        services.AddHealthChecks()
            .AddCheck(
                "Ably Channel",
                AblyChannelHealthCheck(
                    ably,
                    "Notification"
                )
            )
            .AddCheck(
                "Ably Timer",
                AblyTimerHealthCheck(
                    ably,
                    "Topic",
                    TimeSpan.FromSeconds 1.,
                    TimeSpan.FromSeconds 1.
                )
            ) |> ignore
        services
            .AddHealthChecksUI(fun s ->
                s
                    .SetEvaluationTimeInSeconds(60)
                    .AddHealthCheckEndpoint(
                        "Self",
                        $"http://{Dns.GetHostName()}/health"
                    ) |> ignore)
            .AddInMemoryStorage() |> ignore

        ...

    member this.Configure(app: IApplicationBuilder, env: IWebHostEnvironment) =
        ...
        app.UseSwagger(fun opt -> ()) |> ignore
        app.UseSwaggerUI(fun opt ->
                opt.SwaggerEndpoint("/swagger/v1/swagger.json", "Notification Api V1")
                opt.RoutePrefix <- String.Empty
        ) |> ignore
        ...
        app.UseEndpoints(fun endpoints ->
                endpoints.MapControllers() |> ignore
                endpoints.MapHealthChecksUI(fun setup ->
                    setup.UIPath <- "/ui-health"
                    setup.ApiPath <- "/api-ui-health"
                ) |> ignore
                endpoints.MapHealthChecks(
                    "/health",
                    HealthCheckOptions(
                        Predicate = (fun _ -> true),
                        ResponseWriter = Func<HttpContext, HealthReport, Task>(fun (context) (c: HealthReport) -> UIResponseWriter.WriteHealthCheckUIResponse(context, c))
                    )
                ) |> ignore
            ) |> ignore



    On the dashboard, you can check the health of the Ably Channel and the Ably Timer (including Description, Duration, and Details fields).
    Dashboard view of health checks.

    Summary

    This is the whole "enterprise" application that gives you some picture of how you can use Ably in your app. Source code is available here.

    Run all at once

    To run the whole app you can simply run docker compose up since the docker-compose file is in place.

    version: '3'
    volumes:
      retrospectiveLocalDb:
      retrospectiveLocalDbConfig:
    services:
      database:
        image: db
        build:
          context: ./storage/mongo
          dockerfile: ./Dockerfile
        environment:
          - MONGO_INITDB_ROOT_USERNAME=sample
          - MONGO_INITDB_ROOT_PASSWORD=Sample123!
        volumes:
          - retrospectiveLocalDb:/data/db
          - retrospectiveLocalDbConfig:/data/configdb
        ports:
          - '27017-27019:27017-27019'
      topic:
        image: topic
        build:
          context: ./src
          dockerfile: ./Topic/Dockerfile
        ports:
          - '2137:80'
        depends_on:
          - database
        environment:
          MongoDB__Host: database
        hostname: topic
      notification:
        image: notification
        build:
          context: ./src
          dockerfile: ./Notification/Dockerfile
        ports:
          - '2138:80'
        hostname: notification
      facade:
        image: facade
        build:
          context: ./src
          dockerfile: ./Facade/Dockerfile
        ports:
          - '2111:5000'
        depends_on:
          - notification
          - topic
        hostname: facade


    As we can see by this simple example of an "enterprise" application we have shown how you can build a realtime full stack app with .NET, Angular, MongoDB, and Ably.

    About Ably

    Ably is an enterprise-grade pub/sub messaging platform that makes it easy to efficiently design, quickly ship, and seamlessly scale critical realtime functionality delivered directly to end-users. Everyday Ably delivers billions of realtime messages to millions of users for thousands of companies.

    The Ably platform is mathematically modelled around Four Pillars of Dependability to ensure messages don’t get lost while still being delivered at low latency over a secure, reliable, and highly available global edge network. Take the Ably APIs for a spin to see why developers from startups to industrial giants choose to build on Ably to simplify engineering, minimize DevOps overhead, and increase development velocity.
